SHICANE HLR REMOTE + REVOLVER
for Scooters
ADVANCED LIGHTWEIGHT DESIGN
Utilizing aerospace-grade aluminum forging construction and a military-grade surface coating, RACINGBROS achieve weight savings of up to 30% compared to conventional competitors.
Ⓐ REVOLVER
The hydraulic preload adjuster.
Ⓑ CO-AXIAL SYSTEM
Rev up your riding adventure with cutting-edge Co-axial High/Low-Speed Compression Damping System.
Ⓒ BLADDER TECH
RACINGBROS features bladder oil/gas technology to enhance shock sensitivity, with an extra-large reservoir volume ensuring the most stable and comfortable riding experience.
Ⓓ ALUMINUM ALLOY PISTONS
Precisely CNC-machined pistons from high-quality 7-series aluminum ensure consistent damping.
DAMPING
Optimized valving design ensures precise suspension control by regulating oil flow for stability and responsiveness. Shims, precision-engineered steel discs, fine-tune damping in forks and shocks. CNC-machined 7-series aluminum pistons deliver consistent, reliable performance across all conditions.
FEATURES / SPECS
◦ JIS G3560 Cr-Si high-rigidity steel spring, 5–8% lighter than standard springs
◦ Co-axial damping system
◦ 2,500 psi hose with CNC stainless fittings
◦ 14 mm high-rigidity super-chrome shaft
◦ Bladder Oil/Gas separation tech
◦ 6061-T6 cold-forged damper body
◦ 7075-T6 CNC-machined piston
◦ MIT high-precision spherical bearings
◦ Adjustable spring preload
◦ Speed Adaptive Valving
---
Adjustment Range:
Wide-range low-speed rebound: 24 clicks ±3
High-speed compression: 24 clicks ±3
Low-speed compression: 24 clicks ±3
※ Settings may vary. Refer to actual product.
DIMENSION DRAWING
The eye-to-eye length (marked as 'L') and mounting configurations may vary depending on the vehicle’s make, model, year, and customization. All products are custom-made by each distributor. Please consult your distributor to confirm the correct specifications for your setup.
