SHICANE TWIN MONO R
for Minibikes
ADVANCED LIGHTWEIGHT DESIGN
SHICANE, inspired by racing “chicanes” where overtakes happen, is high-performance suspension built for both daily commutes and the racetrack—reliable, durable, and ready for every corner.
ALUMINUM ALLOY PISTONS
Precisely CNC-machined pistons from high-quality 7-series aluminum ensure consistent damping.
FEATURES / SPECS
◦ JIS G3560 Cr-Si high-rigidity steel spring, 5–8% lighter than standard springs
◦ 14 mm high-rigidity super-chrome shaft
◦ 7075-T6 CNC-machined piston
◦ 6061-T6 cold-forged damper body
◦ MIT high-precision spherical bearings
◦ Adjustable spring preload
◦ Adjustable length
◦ Speed Adaptive Valving
---
Adjustment Range:
Low-speed rebound: 24 clicks ±3 (MONO-R only)
※ Settings may vary. Refer to actual product.
---
Length Options:
298 mm (DAX)
340 mm (DAX)
285 mm (MONKEY)
330 mm (MONKEY)
360 mm (CT125)
COMPATIBILITY
HONDA
CT 125
DAX
MONKEY
TECHNICAL DRAWING
The eye-to-eye length (marked as 'L') and mounting configurations may vary depending on the vehicle’s make, model, year, and customization. All products are custom-made by each distributor. Please consult your distributor to confirm the correct specifications for your setup.
